Spotters 14
Slide 2
Caffey's disease. Gross periostitis affects the ribs and the mandible is also thickened.
Slide 3
Sagittal T,-weighted image of the knee. The medial meniscus
i s torn. There is a large Baker's cyst which contains loose bodies.
Slide 4
Osteoblastoma of the left pedicle and lamina of L3. (A) Conventional oblique radiograph showing expansion and sclerosis.
Slide 5
CHAIRI MALFORMATION III
High cervical/low occipital encephaloceles are present .
The encephaloceles contain varying amounts of brain
÷cerebellum & occipital lobes
÷ ventricles
÷medulla & Pons
÷aberrant deep draining veins and ectopic venous sinuses within the encephaloceles
Slide 6
OS ODONTOIDEUM
Slide 7
R ATRIUM HYDATID CYST
Slide 8
HYDATID CYST BRAIN
Slide 9
UTERINE AVM
Slide 10
sub mucosal masses, GIST similar to those of leiomyomas and leiomyosarcomas
Slide 11
PV GAS & PNEUMOBILIA
Slide 12
HEMANGIOMA
Slide 13
ASCARISIS IN CBD
Slide 14
ABC
Slide 15
FRONTAL SINUS MUCOCELE
Slide 16
ANNULAR PANCREAS: MRCP demonstrates panc. duct encircling the duodenum
Slide 17
OSTEOPOIKILOSIS
Slide 18
avm
Slide 19
Calve's disease (vertebra plana)
Slide 20
Fibrolamellar Hepatocellular Carcinoma
Slide 21
Tumoral CALCINOSIS
Slide 22
Hamartoma of Tuber Cinerium
Slide 23
ACROMEGALY MACROADENOMA
Slide 24
Chondroblastoma in the proximal epiphysis of the tibia. The
tumour has thinned the overlying cortex and extends across the growth
plate into the upper metaphysis.
Slide 25
DUODENAL LIPOMA
Slide 26
EMPHY PANCREATITIS
Slide 27
ECTOPIC TESTIS
Slide 28
CYSTICERCOSIS
Slide 29
LEAD POISONING
Slide 30
ASCARIASIS
Slide 31
Left mastectomy
Slide 32
PANCAKE KIDNEY
Slide 33
Psoriasis. Sausage digit .soft tissue swelling. Periostitis. Increase bone density.
The distal interphalangeal joints are involved in this
condition. Bone density is often preserved. Erosions proceed along the
bases of the distal phalanges and there is splaying of bone locally. Despite
the erosive change, the joints may be increased in width or, alternatively,
fused. These changes are totally unlike those seen in rheumatoid arthritis
both in appearance and distribution. There is also a neurotrophic change at
the distal and middle phalanges, with longitudinal and concentric bone
resorption, producing a 'licked candy stick' appearance.
Slide 34
Ewings rib
Slide 35
A tension pneumothorax
There is a large, right-sided, tension pneumothorax that is displacing the heart and mediastinal structures to the left. Tension pneumothoraces can result from penetrating injuries or can arise spontaneously. They are serious because air exchange is compromised in both the lung with the pneumothorax and the opposite lung which is being compressed. They are treated by decompressing the tension and re-expanding the lung
Slide 36
Sacrococcygeal teratoma is the most common solid tumor of the fetus and neonate, with a reported incidence of one in 35000 to 40000 live births. It is a neoplasm composed of tissues from all three germ layers, arising from totipotent somatic cells that originate from the primitive knot (Hensen's node) or caudal cell mass.
Slide 37
A ruptured gastric ulcer
There is a huge amount of free air in the peritoneal cavity that is allowing you to see the entire diaphragm very clearly, since it is now outlined by air on both sides. Normally, the diaphragm is not seen as a line on radiographs because the soft tissues in the peritoneal cavity provide no contrasting density to outline its undersurface. Free intraperitoneal air is almost always from a ruptured viscus which itself contained air. In this case, the patient had a perforated duodenal ulcer which was treated surgically
Slide 38
Uretric calculus
Slide 39
Sturge Weber Syndrome
Encephalotrigeminal angiomatosis
Tram-track gyriform cortical calcification with hemiatrophy beneath meningeal angioma due to anoxia (steal)
Choroid plexus enlargement ipsilateral to angiomatosis
Slide 40
Morgagni Hernia
Slide 41
Anterior Sacral Meningocele
